This faithful recreation of the renowned Super Reverb of 1963-1968 is a must-have for vintage enthusiasts and Stratocaster® guitar slingers, although players of all styles enjoy its shimmering tone. With medium output and four 10" speakers, the '65 Super Reverb delivers stage-filling sound perfect for cranking in clubs and on larger concert stages, and its authentic vintage mid-'60s styling takes you back to an electrifying era.
General
SERIES: American Vintage
COLOR: Black and Silver
AMPLIFIER TYPE: Tube
COUNTRY OF ORIGIN: US
PLATFORM: Pro Tube
Electronics
CONTROLS: Normal Channel: Bright Switch, Volume, Treble, Bass; Vibrato Channel: Bright Switch, Volume, Treble, Middle, Bass, Reverb; Vibrato: Speed, Intensity
CONTROL PANEL: Normal Channel: Bright Switch, Volume, Treble, Bass; Vibrato Channel: Bright Switch, Volume, Treble, Middle, Bass, Reverb; Vibrato: Speed, Intensity
INPUTS: Four - (1/4", Two Normal and Two Vibrato)
CHANNELS: Two - (Normal and Vibrato)
EFFECTS: Reverb
EFFECTS LOOP: NA
CONNECTION TYPE: 1/4"
VOLTAGE: 120V
WATTAGE: 45 Watts into 2 Ohms
Hardware
CONTROL KNOBS: Vintage-Style Skirted Black Plastic
AMPLIFIER COVERING: Black Textured Vinyl
CABINET MATERIAL: Birch Plywood
GRILLE CLOTH: Silver
HANDLE: Molded Plastic Strap with Nickel-Plated Caps
AMPLIFIER JEWEL: Red Jewel
SPEAKER JACK: Two 1/4" Parallel (Internal and External)
FRONT PANEL: Black
REVERB TANK: 4-Spring, 8 ohm Spring Reverb Unit 4AB3C1B (p/n 0064063049)
REVERB TANK TYPE: 4-Spring, 8 ohm Spring Reverb Unit 4AB3C1B (p/n 0064063049)
Speakers
SPEAKERS: Four - 10" Jensen® P10R with Alnico Magnet
TOTAL IMPEDANCE: 2 ohms
Tubes
POWER TUBES: 2 x 6L6
PREAMP TUBES: 4 x 12AX7, 2 X 12AT7
RECTIFIER: Tube (1 x 5AR4)
Measurements
DIMENSIONS: 15.00x30.00x30.00 IN
SHIPPING WEIGHT: 55.00 LB
PRODUCT DEPTH: 10.5" (26.7 cm)
PRODUCT HEIGHT: 24.88" (63.2 cm)
PRODUCT WIDTH: 25.125" (63.8 cm)
POWER TUBES: 2 x 6L6
SHIPPING LENGTH: 30.00 IN
SHIPPING HEIGHT: 15.00 IN
SHIPPING WIDTH: 30.00 IN
Accessories
FOOTSWITCH: 2-Button Vintage Style (Reverb On/Off, Vibrato On/Off), P/N: 0994058000 (Included)
