Loaded with premium features, this Pro-Mod Plus Dinky® DK24 2PT model features a sleek Dinky® body constructed from basswood, sculpted shredder's cut heel and scalloped lower back bout for seamless access to the upper registers. The bolt-on caramelized maple neck features graphite reinforcement for rock-solid stability, a satin natural finish on the back of the neck for sublime playability, and a conveniently located heel-mount truss rod adjustment wheel for neck relief tweaks on the fly. Designed for speed, the 12"-16" compound radius ebony fingerboard features comfortable rolled edges, 24 stainless steel jumbo frets and Luminlay® side-dots for enhanced visibility in low-light conditions.
This axe features an HH pickup configuration consisting of a direct mount Seymour Duncan® Full Shred™ TB-10 bridge pickup and direct mount Seymour Duncan® Alnico Pro II™ APH-1N neck pickup. The bridge pickup radiates a crisp top-end with low-end articulation, while the neck pickup has incredible range with soaring highs and silky lows.
Other premium modern features include a five-way blade pickup switch, speed knobs for the volume and no-load tone controls, Wilkinson® recessed tremolo bridge with locking saddles, Charvel-branded die-cast locking tuners and more.
Blending sophisticated style with assertive tone, the Pro-Mod Plus Dinky® DK24 2PT HH E delivers premium performance and modern features.
Features
25.5" scale length
Basswood Dinky® body
Scalloped lower back bout
Bolt-on maple neck with graphite reinforcement
Sculpted shredder's cut heel
12"-16" compound radius ebony fingerboard with 24 jumbo stainless steel frets
Heel-mount truss rod adjustment wheel
Direct mount Seymour Duncan® Full Shred™ TB-10 humbucking bridge and Seymour Duncan Alnico II Pro™ APH-1N humbucking neck pickups
Five-way blade switch, volume control and no-load tone control
Wilkinson® WVS130-2p tremolo bridge with locking saddles
Product Name: Pro-Mod Plus DK24 HH 2PT EB - Ebony Fingerboard - Raven Black
Model #: 2972811503
General
SERIES: Pro-Mod Plus
ORIENTATION: Right-Hand
COLOR: Raven Black
COUNTRY OF ORIGIN: ID
Neck
HEADSTOCK: Licensed Fender® Stratocaster®
NECK MATERIAL: Caramelized Maple
NECK FINISH: Natural Satin
NECK SHAPE: Speed Neck with Rolled Fingerboard Edges
NECK CONSTRUCTION: Bolt-On with Graphite Reinforcement
FINGERBOARD RADIUS: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
FINGERBOARD MATERIAL: Ebony
POSITION INLAYS: 4mm Pearloid Dot
SIDE DOTS: Luminlay®
NUMBER OF FRETS: 24
TRUSS ROD: Dual-Action with Wheel
TRUSS ROD NUT: Heel-Mount Truss Rod Adjustment Wheel
STRING NUT: Graph Tech TUSQ XL
NUT WIDTH: 1.6875" (42.86 mm)
NUT MATERIAL: Graph Tech TUSQ XL
FRET SIZE: Jumbo Stainless Steel
SCALE LENGTH: 25.5" (648 mm)
Body
BODY: Basswood
BODY FINISH: Gloss
BODY SHAPE: Dinky®
BODY STYLE: Solid Body
BODY MATERIAL: Basswood
Hardware
BRIDGE: Wilkinson® WVS130-2P Tremolo
PICKGUARD: None
PICKUP COVERS: Black
CONTROL KNOBS: Speed Knob
SWITCH TIP: Black
HARDWARE FINISH: Chrome
TUNING MACHINES: Charvel®-Branded Die-Cast Locking
STRING TREES: Fender® Standard String Guide
STRINGS: Nickel Plated Steel (.009-.042 Gauges)
TREMOLO ARM: Wilkinson®
NECK PLATE: None - 4-Bolt Sculpted Heel
STRAP BUTTONS: Standard
Electronics
BRIDGE PICKUP: Seymour Duncan® Full Shred™ TB-10
NECK PICKUP: Seymour Duncan® Alnico II Pro™ APH-1N
PICKUP CONFIGURATION: HH
CONTROLS: Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone
SWITCHING: 5-Position Blade: Position 1. Bridge Pickup, Position 2. Both Outer Coils, Position 3. Bridge and Neck Pickup, Position 4. Both Inside Coils, Position 5. Neck Pickup
AUXILIARY SWITCHING: 2-Position Mini Toggle Down/All Series, Up/All Parallel
Measurements
SHIPPING DIMENSIONS: 4.00x21.00x50.00 IN
SHIPPING WEIGHT: 17.19 LB
SHIPPING LENGTH: 50.00 IN
SHIPPING HEIGHT: 4.00 IN
SHIPPING WIDTH: 21.00 IN
