Studio Mango Limited Edition
The Studio Mango Limited Edition brings a fresh visual face to one of PRS’s most versatile instruments. Built on the proven Studio platform, this special edition pairs a figured mango top with a striking ziricote fretboard, adding organic warmth and depth to the guitar’s aesthetic while preserving the dynamic, wide-ranging tone the model is known for. Only 200 total Studio Mango Limited Editions will be available in 2026.
The Studio pairs PRS proprietary Narrowfield pickups in the bass and middle positions with a McCarty III humbucking treble pickup, offering both articulate single-coil-inspired clarity and full, musical humbucking power. The electronics layout – volume, push/pull tone control, and 5-way blade switch – unlocks a range of voices suited for studio precision or live performance.
With a mahogany back and neck, 22 frets, and a 25” scale length, the Studio platform delivers the familiar playability and feel PRS is known for. Anchored by PRS’s patented Gen III tremolo and Phase III locking tuners with wing buttons, this instrument offers expressive performance with exceptional tuning stability.
Whether you’re chasing vintage shimmer, crisp rhythm tones, or cutting lead sounds, the Studio Mango Limited Edition delivers a wide spectrum of expressiveness in a single, beautifully crafted instrument – an inspiring choice for players who rely on one guitar to do it all.
Specifications
Body
Body Construction: Solidbody
Top Wood: Figured Mango
Back Wood: Mahogany
Top Carve: Violin Carve
Neck
Number of Frets: 22
Fret Wire: PRS Standard
Width of Fret Crown: .104”
Height of Fret Crown: .047”
Scale Length: 25”
Neck Wood: Mahogany
Neck Construction: One-Piece
Truss Rod: PRS Double-Acting
Neck Shape: Pattern
Neck Depth at the 1/2 Fret: 7/8”
Neck Depth at the 12 1/2 Fret: 61/64”
Neck Width at the Nut: 1 11/16”
Neck Width at the Body: 2 1/4”
Fretboard Wood: Ziricote
Fretboard Radius: 10”
Fretboard Inlay: Old School Birds with Outlines
Headstock Veneer: Ziricote
Headstock Inlay: Inlaid Signature
Neck/Body Type: Set
Assembly Finish
Finish Type: Gloss Nitro
Hardware
Bridge: PRS Patented Tremolo, Gen III
Tuners: PRS Phase III, Locking
Hardware Type: Smoked Black
Nut: PRS
Truss Rod Cover: Studio
Electronics
Treble Pickup: PRS McCarty III T
Middle Pickup: PRS Narrowfield
Bass Pickup: PRS Narrowfield
Controls: Volume & Push/Pull Tone Control with 5-Way Blade Pickup Switch
Additional Information
Strings: PRS Signature, 10-46
Tuning: Standard (6-String): E, A, D, G, B, E
Included Accessories: Hardshell Case
