The DigiTech Drop is a specialized polyphonic pitch-shifting pedal that lets you lower your guitar's tuning from a single semitone down to a full octave—no need to swap instruments. It delivers deep, heavy tones on the fly. The pedal also includes a momentary/latching footswitch. In momentary mode, it becomes a powerful tool for expressive playing, perfect for quick pitch shifts, trills, and dramatic dive effects—all right under your foot.
CONTROLS
• EFFECT SELECTOR KNOB- Selects which of the Drop effect settings is used when the effect is active.
• MOMENTARY ON/OFF SWITCH - Selects how the effect footswitch will operate. Setting this switch to ON will cause the footswitch to act as a momentary switch (the effect will be enabled or disabled only as long as the footswitch is pressed and held). Setting this switch to OFF will cause the footswitch to act as a standard latching on/off switch.
Drop Effects Settings
Setting 1 - Transposes guitar signal down 1 semitone
Setting 2 - Transposes guitar signal down 2 semitones
Setting 3 - Transposes guitar signal down 3 semitones
Setting 4 - Transposes guitar signal down 4 semitones
Setting 5 - Transposes guitar signal down 5 semitones
Setting 6 - Transposes guitar signal down 6 semitones.
Setting 7 - Transposes guitar signal down 7 semitones
Setting OCT - Transposes guitar signal down 1 octave.
Setting OCT + DRY - Transposes guitar signal down 1 octave and adds dry signal
Note: A semitone is the smallest interval used in classical Western music, equal to a twelfth of an octave or half a tone; a half step.
FEATURES:
• Advanced Polyphonic Drop Tune Algorithm
• Drop From 1 Semi-Tone to a Full Octave
• Momentary or Latching Mode
• 9VDC Power Supply Included
• True Bypass
SPECIFICATIONS
Input: 1/4" Unbalanced (Tip-Sleeve)
Output: 1/4" Unbalanced (Tip-Sleeve)
Controls: Amount, Momentary On/Off
A/D/A Converter: 24-bit
Sampling Rate: 44.1 kHz
Power Supply: PS0913DC-01 (US, JA); PS0913DC-02 (EU, AU, UK)
Weight: 0.36 lbs. (0.163 kgs.)
Dimensions: 4.75 (L) x 2.875 (W) x 1.75 (H)
Included Items:
• DigiTech Drop Polyphonic Drop Tune Pedal
• PS0913DC Power Supply
• Online Owners Manual and Warranty Registration Information Card
